Used in offices, hospitals, schools and other places to meet lighting needs and achieve decorative functions
Export quality
Professional design
Self-developed products
Worry-free after-sales
Features:
Side light source LED light bar, high-power lamp beads, full power, high brightness, stable quality, uniform light output, more concentrated light, no distortion; optical lens 10X45 degrees, uniform light output, no dark areas; high-conductivity aluminum substrate, heat dissipation Fast and long life; suitable for the needs of various light boxes.
| Date | 2021-7-31 |
| Quantity | 5 beads |
| Lamp name | LED light box light bar |
| Specification model | qmd-dxdt-3535-5d-364-w-24v |
| Lamp brand | Qimingda |
| Application location | Customer's choice |
| Installation method | Light box frame installation |
light source | |
| Light effect | 120-130LM/W |
| Color temperature | 2700-6500K optional |
| Power source | 3-5W |
| Light source brand | CREE |
| Light source type/specification | SMD3535 |
Lamps and electrical appliances | |
| Protection level | IP43 |
| Input voltage | DC 24V |
| Power factor | 90 |
| Hole Size | 364*28*2.0 |
| Beam angle/lens | 60 degrees/15*45 degrees |
| Shade material/color | / |
| Light body material/color | PCB aluminum substrate |
| Electrical appliances/specifications/installation methods | Light box frame installation |
| Power (number of light sources x light source power) | 15W |
| Lamp life (system is not a single light source) | 50000h |
